Efficient motor configuration
A 36-volt 250-watt brushless hub motor is installed directly on the front wheel. This design offers smooth instantaneous timing and enables a faster acceleration process with a maximum speed of 25 kilometers per hour.
Energy and Mileage
The power comes from a 36-volt, 7 ampere-hour lithium-ion battery pack, which can be charged easily. Under standard testing conditions, after being fully charged, it can support approximately 30 kilometers of mileage, perfectly covering daily commuting needs.
Energy recovery
Just connect it to the standard charger for 4 to 5 hours, and you can quickly restore all the power, easily meeting your daily usage needs.
vehicle
The main structure is made of lightweight and high-strength aluminum alloy, which has been precisely forged to achieve the optimal balance between durability and practicality. The net weight of the entire vehicle is 14.55 kilograms.
Tires and shock absorbers
Equipped with two 8.5-inch inflatable tires, the air inside the tires can effectively absorb and cushion the closing of the tire response. Compared to solid tires, the walking comfort and grip have significantly improved.
Weight capacity
With its overall structural design, its maximum static load-bearing capacity reaches 150 kilograms, making it suitable for most products.
Illuminating system
It integrates a complete lighting solution, including high-brightness headlights for night road lighting and red rear taillights for safety warnings, ensuring visibility and safety for walking during dusk and night.
Data display
A dedicated LCD display instrument is integrated on the control riser, which transmits real-time speed, progress and movement distance to the walker. All the data is clearly visible.
TOP-ES09 parameters
| Outer Box Dimensions | 109 x 15 x 50 mm | Maximum Speed | Approximately 25 km/h |
| Weight | 14.55 kg | Battery | 36V x 7Ah lithium-ion battery |
| Tire Diameter | 8.5 inches | Braking System | Hand brake |
| Front Fork | Toothless Steel Front Fork | Lighting | Front headlight + taillight |
| Tires | 8.5-inch Pneumatic Tires | Charging time | 4-5 hours |
| Motor | 8.5-inch Front-Drive Motor 36V 250W | Range | 30 kilometers |
| Instrument Panel | Scooter-specific upright tube instrument panel | Maximum load | 150 kg |
| Maximum climbing angle | 10 degrees |
